Diamondback Line 24"

Diamondback Line 24"
Matte Silver
Please select options
You may purchase this item online, however the manufacturer prefers that we sell this item in-store only. You may pick this up at any of our nine locations.


A bike they can grow with, the Line 24" is a junior version of our do-anything hardtail mountain bike.

Equipped to handle the abuse of real mountain bike trails and daily use around the neighborhood, it’s made from the same aluminum as our full-size bikes, so it’s practically indestructible. An SR Suntour fork performs like the big people’s bikes, giving your ripper-to-be 80mm of front suspension travel.

The 24-inch wheels are stiff and stable, shod with aggressive 2.25-inch wide Vee Rubber tires: perfect for tearing up the woods. Disc brakes and a wide-range SRAM 1×8 drivetrain are real performance features, underscoring that the Line 24" is a legit mountain bike—only smaller.

This model fits riders 53” – 62” tall, aged approximately 8 – 12 years old.


Frame 6061 T-6 Aluminum Jr-24" Frame, Formed Tubing, Disc Specific w/ Replacable Hanger
Fork SR Suntour XCT JR 24", 80mm Travel, 28mm Stanchion, Alloy Lowers, w/ Preload Adjust
Headset FSA IS-3/NO.11 Integrated Style
Rims/Wheels 32h Diamondback Doublewall
Hubs Front: 32h Alloy w/ CNC Disc Mount
Rear: 32h Alloy w/ CNC Disc Mount, Cassette
Spokes 14g Stainless Steel
Tires Vee Rubber Crown Gem, 24x2.25"
Crankset Alloy Arm, w/ 32T Steel Single Ring, 155mm
Bottom Bracket Sealed Cartridge
Chain KMC Z82, 8 Speed
Front Derailleur Upper Chain Guide, 34.9 Clamp Diameter
Rear Derailleur SRAM X3, 8 Speed
Cassette/Rear Cogs SRAM PG820 Cassette, 8 Speed, 11-32T
Shifters SRAM X4 8 Speed
Handlebars Diamondback, 720mm Wide, 15mm Rise, 31.8 Bar Bore
Tape/Grips New DB "Flanged" 135mm Silcone
Stem Diamondback "Shortie", 45mm Reach, 31.8 Bar Bore
Brake Levers Tektro 2 Finger Alloy Linear w/ Reach Adjust
Pedals DB4L Resin Platform
Saddle DB Sync'r Jr. Saddle
Seat Post Alloy Micro Adjust, 27.2mm

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Matte Silver / 24-inch 791964574132 02-0510060 210000029768
